- Full-waveform furnace structure avoids cracking caused by stress concentration, extending boiler's service life.
- Unique "welding & expansion" process prevents subcooled boiling at the tube and plate welds, ensuring a safe, reliable and stable boiler operation.
- Staggered tube bundles facilitate steam drums carrying and evenly distribute heat to the tube walls.
- Rational set of flue gas temperature at three-pass outlet prevents low-temperature corrosion.
- Multifunctional explosion-proof doors ensure safe use and easy maintenance.
- Independent design of fixed movable supports allows for flexible thermal expansion and contraction.
Performance Feature -Energy Saving
- Increased heating surface of the tail finned tubes provides higher heat exchange efficiency
- Smoke tube adopts special threaded tube to reduce smoke flow resistance and enhance the heat transfer effect.
- Economizer (condenser) adopts patented technology with independent intellectual property rights, taking into account both heat transfer efficiency and operation resistance;
- Multi-stage "stepped" sealing provides excellent thermal insulation and sealing performance.
- Frameless outer-clad structure & entire coating with heat-resistant paint minimize the heat losses.
Performance Feature -Emission Reduction
- Large combustion chamber design enables fuel to burn more fully and thoroughly at a relatively low furnace volume heat load, and nitrogen oxides are less than 30mg/Nm³.
